FBT announces its new Muse Series subwoofers, the Muse 188FSCA/FSA reversible flyable subwoofer, and Muse 118FSC/FS flyable passive subwoofer.
More details from FBT (www.fbt.it):
RECANATI, Italy -The Muse 118FSA is a true reversible flyable subwoofer. Designed and manufactured by FBT’s renowned engineers and artisans, the Muse 118FSA is a prime example of audio perfection with ergonomic innovations. The Muse 118FSA is a hybrid loaded 18’’ neodymium subwoofer designed to suspend from the Muse flybar either facing forward or rearward. When flown facing rearward, the sub’s user removable grille can be moved by the user to the new “front” of the enclosure and the amplifier module can be moved to the new ‘rear’ of the enclosure, thus obtaining aesthetic consistency when flown with additional forward facing Muse 118FSA’s. Thus, when creating a cardioid sub package, no additional hardware is needed to easily achieve sleek visual continuity. The model MUSE 118FSCA is already factory preconfigured as rear facing for cardioid applications
MUSE 118FSA
Processed Cardioid-Flyable Active Subwoofer
1200W – 139dB SPL
- Compact Hybrid band pass cardioid-arrayable subwoofer. Hybrid configuration permit to obtain extension and speed of vented with high SPL and acoustic filtering of band pass
- Suspension hardware fully compatible with MUSE210La allowing the enclosure to be suspended front or rear-firing for easy cardioid configurations
- Subwoofer can be suspended facing forward or rearward and user-configurable with capability of front- or rear- mounting the grille and amp module for aesthetic uniformity in cardioid configuration.
- Very large area laminar-flow port to ensure no power compression and very low port turbulence
- For cardioid configurations with one SUB rear-firing and two sub front-firing, more than 15db SPL rejection can be obtained behind the array
- 18’’ (460mm) custom B&C neodymium magnet high excursion woofer with 3’’ (75mm) voice coil
- Frequency Response from 33Hz to 100Hz
- Class D amplifier delivering 1200WRMS
- Switch mode power supply
- DSP with 8 presets, cardioid and with infra configurations, delay
- Control panel with XLR input and link, volume, presets, delay, phase 0°-180°, ground-lift
- 5/8’’ (15mm) birch plywood enclosure, scratch resistant black paint
- Low frequency extension cabinet for the MUSE 210LA line array for flying or ground stacked configurations.
- Very low profile for a 18’’ size woofer
- It’s possible to order Muse 118FSCA model that’s the version already factory preconfigured as rear facing for cardioid applications
MUSE118FS
Flyable Passive Subwoofer
1200W – 139dB SPL
- Passive version, recommended amplifier of 1200Wrms / 8ohm
- NeutrikSpeakon NL- 4MDV connectors IN & LINK OUT
- External digital processor required
