Royal Edinburgh Military Tattoo and Wigwam Acoustics Use TiMax Tracking System for Control

FOH Staff • International News • December 2, 2019

Wigwam Acoustics’ setup included the largest TiMax TrackerD4 precision stagetracking system to date

EDINBURGH, Scotland – This year’s Royal Edinburgh Military Tattoo made use of a massive audio tracking system for control. Wigwam Acoustics’ setup included the largest TiMax TrackerD4 precision stagetracking system to date. The system controlled a pair of Out Board’s TiMax SoundHub-S64 spatial audio processors with new HARDCore FPGA processing.

More details from Out Board (

The Royal Edinburgh Military Tattoo Finale Fireworks.

This year’s Royal Edinburgh Military Tattoo undertook one of its biggest technological transformations to date. For the first time in its history, the vast and complex event trusted its audio control to an audio tracking system, implementing the largest TiMax TrackerD4 precision stagetracking system yet, controlling a pair of Out Board’s TiMax SoundHub-S64 spatial audio processors featuring new HARDCore FPGA processing – all supplied by Wigwam Acoustics.

Since 2014, sound designer, Seb Frost, has overseen the execution of audio reinforcement for the event, in which a continuously moving cast of over 1000 military musicians march through Edinburgh Castle’s parade ground in increasingly complex configurations.

The Royal Edinburgh Military Tattoo Dance Company and The Massed Military Bands

Frost claims, “TiMax TrackerD4 dramatically improved the accuracy and resolution of the loudspeaker system. The advantage was that because everything sounded so natural we could increase the volume, which 100% had the effect of engaging the crowd and giving them – dare I say it – a more immersive experience!”

Along with 60 channels of radio microphone, 48 TiMax Tracker tags were swapped onto performers every four to six minutes during the course of the 100-minute performance. Over 700 tag swaps, from full bands to individual and group performances, demonstrates the level of complicated organisation that lies behind this unique event.

Performers from China, France, Germany, New Zealand and Trinidad and Tobago, as well as homegrown talent from the UK, participated.

The TTd4 tags drive a 48-channel TiMax2 SoundHub audio spatialisation matrix to continuously maintain localization and musical timing integrity for the whole audience. TiMax has been used to clarify the audio imaging for the Royal Edinburgh Military Tattoo since 1994. Frost explains, “TiMax is still the only product on the market that can do what it needs to do for the Tattoo, which is spatially control the reinforcement in a three-sided arena.”

The Massed Pipes and Drums.

The decision to use tracking on the event was made based on, “…alongside accuracy and cost, the small size of the TiMax TrackerD4 tags and their extraordinarily long battery life.” Frost confirms, “It was absolutely a worthwhile investment and something we’ll roll out elsewhere as soon as possible.”

To ensure the smooth integration of the largest D4 system used to date, Out Board’s Robin Whittaker was on hand, providing in Frost’s words, ‘fantastic support’. Frost goes on to explain, “We were able to send back gigabytes of data and the Tracking team at Out Board analyzed it and sent back a new set of filters, so we were able to improve resolution and accuracy in a very short space of time – with such great support.”
